Unilay HR FR
- REACH
- RoHS
- CE
- CPR Compliant
India’s 1st Heat Resistant and Flame Retardant REACH Compliant Cable with Unilay Conductor. No Loose Contacts, No Broken Ends | No Sparking and Overheating
Application
Suitable for use in conduit and for fixed, protected installation, ideal for high density wiring.
Technical Data
Approvals: IS 694 marked, FIA / TAC
Voltage Grade: Up to and including 1100V
Conductor: Thin strands of electrolytic copper are multi-drawn for uniformity of resistance, dimension and flexibility. The drawn strands are uni-laid with high precision and compacted. Thus forming a perfectly circular conductor which enables reduction in overall diameter for space saving in high density wiring.
Conductor Speciality: The strands do not get cut when stripping the insulation. The conductor offers perfect contact at pins, terminals and sockets. Thus, eliminating spot heating and sparking.
Insulation: Specially formulated heat resistant & flame retardant PVC insulation is used. The HR FR property retards the propagation of flame without compromising safety.
Insulation Conformity: IS 5831, Type C – HR 85°C + FR
Cabel Design Parameters
Kindly complete the part numbers for these cables by adding the suffix (in place of ‘xx’) for the colour required:
01 – Green, 02 – Black, 03 – Red, 04 – Blue, 05 – Yellow, 06 – Grey, 07 – White
Part Number | Nominal Cross Sectional Area (sq. mm) | Nominal Insulation Thickness (mm) | Number / *Max. Dia. Of Strands | Approx. Overal Diameter (mm) | Max.DC Conductor Resistance at 20C (Ω/km) | Current Rating (Amps) | |
Casing | Concealed | ||||||
01030101xx40 | 1.0 | 0.7 | 37/0.19 | 2.6 | 19.5 | 14 | 13 |
01030102xx40 | 1.5 | 0.7 | 37/0.23 | 3.0 | 13.3 | 18 | 16 |
01030103xx40 | 2.5 | 0.8 | 61/0.23 | 3.6 | 7.98 | 24 | 20 |
01030104xx40 | 4.0 | 0.8 | 61/0.29 | 4.1 | 4.95 | 32 | 26 |
01030105xx40 | 6.0 | 0.8 | 91/0.29 | 4.6 | 3.30 | 38 | 33 |
- *Conductor as per IS 8130
Properties
Test | Test Test Method | Values |
Limited Oxygen Index | IS 10810 P-58 | > 29% |
Limited Temp. Index | IS 10810 P-64 | >250 °C |
*Construction Product Regulation (CPR) is a regulation issued by the European Union with the purpose of regulating the limits of fire resistance and dangerous substances in the materials used in construction. This regulation applies to all products intended to be incorporated, permanently, in construction. Above link provides the DOP (declaration of performance) for the CPR compliance for the product.)
